CM50 Mother-in-law Plug-in Wall Panel System

Figure 1: Breakdown of the connection method of the machine board

Fast, simple and flexible installation;
rock wool board fire protection time > 1 hour;
good thermal insulation performance;
suitable for clean rooms from 10000 to 100K.

CM50 system wall panel corresponding parameters (optional) are as follows

Matching wall panel thickness

50/60mm

75/80mm

100/120mm

External surface material

0.5mm color coated steel plate

0.6mm color coated steel plate

Surface coating

Polyester PE

glue

Polyurethane glue

Core material

100kg/m³ / 120kg/m³ Rockwool

Single-sided/double-sided glass magnesium

frame

No sealing on the top and bottom, male and female grooves on the long side

Certification

FM4882, fire protection grade A1, fire resistance time limit 0.5-2 hours

Features

Not removable, height adjustable
